Application:To fill products like Ginger Garlic Paste, Tomato sauce, Ketchup, Jam, Jelly, Fevicol, Adhesive & Tamarind Paste, Pickle.
Description:Single head pneumatically operated fully automatic form fill & seal machine to pack "Paste Products" in pouches with heat sealable laminated poly pouches.
Product Range:Up to 100 & 200 grams
| 1 | Feeding head | Pneumatic piston filling system. |
| 2 | Production Speed | 30- 40 pouches / minute. |
| 3 | Machine control system | Digital Control System. |
| 4 | Packing range | Up to100 & 200 grams |
| 5 | Film Width | 120 mm. |
| 6 | Film Thickness | 50 - 80 microns. |
| 7 | Film Material | Laminated. |
| 8 | Sealer heating system | Continues. |
| 9 | Inner Core Dia. of Film Roll | 70mm. |
| 10 | Outer Dia. of the film Roll | up to 280mm. |
| 11 | Pouch Style | 3 side Seal. |
| 12 | Pouch Width | up to 120mm. |
| 13 | Pouch Length | up to 240mm. |
| 14 | Power Consumption | 1 kW / Hour. |
| 15 | Peak Power | 3 kW |
| 16 | Power requirement | Single Phase, 220 V, 50Hz plus Neutral. |
| 17 | Pouch Counter | Provided. |
| 18 | Photo Cell | Provided |
| 19 | Batch Cutter | Provided on extra cost. |
| 20 | Machine Dimensions in 'mm' | 2715(H) x 1000(W) x 1910(Depth). |
| 21 | Net Weight | 600kgs (approx). |
"Design and Manufactures of Flexible Pouch Packaging Machines"
